NRND = Not Recommended for New Design
Inactive Datasheet Archive
Contact Sales
Log in or register to manage email notifications about changes to datasheets or PCNs for this part.
| @ IF (A) | 2 |
|---|---|
| @ TerminalTemperature TT (ºC) | N/A |
| @ VR (V) | 80 |
| Configuration | N/A |
| Forward VoltageDrop VF(V) | 0.79 |
| MaximumAverageRectifiedCurrent IO (A) | 2 |
| Maximum ReverseCurrent IR (µA) | 0.2 |
| Peak ForwardSurge CurrentIFSM(A) | 50 |
| Peak RepetitiveReverse VoltageVRRM (V) | 80 |
| AEC Qualified | No |
| Reverse RecoveryTime trr (ns) | N/A |
| TotalCapacitance CT (pF) | 70 |
A PCN may only apply to specific orderable part numbers in this datasheet. Please refer to the corresponding PCN to see the exact orderable part number(s) affected.
| PCN # | Issue Date | Implementation Date | Subject |
|---|---|---|---|
| PCN-2460 | 2020-05-12 | 2020-05-12 | Qualified Additional Wafer Source and BGBM Source |
